Technical Support & Innovative Manufacturing

Manufacturing Excellence
Step into our IATF 16949 certified facility, where precision meets scale. We utilize world-class Gleason milling and grinding machines alongside automated heat treatment lines to ensure every gear achieves superior hardness and dimensional stability.

Standardized Lifecycle
Experience a seamless transition from PPAP (sample development) to full-scale mass production. Our standardized delivery cycles are backed by rigorous quality control protocols, ensuring 100% reliability at every stage of the manufacturing process.

Industry-Specific Solutions
We provide specialized gear design solutions tailored for commercial vehicles and beyond. By analyzing the unique torque and environment requirements of these four major sectors, our engineers deliver optimized performance for every application.

Technical Resources & Support
Accelerate your project with instant access to our latest product catalog and installation manuals. We also provide comprehensive failure analysis guides to help you maintain peak operational efficiency
Comparison Table of Gear Precision Grade
Country | Standard | Precision Grade | ||||||||||
USA | ANSI | 4 | 3 | 2 | 1 | |||||||
USA | AGMA | 16 | 15 | 14 | 13 | 12 | 11 | 10 | 9 | 8 | 7 | 6 |
Japan | JIS | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | ||
International | ISO | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 |
China | GB | 3 | 4 | 5 | 6 | 7 | 8 | 9 | ||||
Germany | DIN | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 |
UK | BS | A1 | A1 | B | C | D | ||||||
France | FN | A | B | C | D | E |
Technical Highlights
Global Material Standards
☑We strictly adhere to international material specifications to ensure peak performance across all applications.
International Precision Grades
☑Utilizing our advanced measuring center, we guarantee precision alignment with multiple global standards.
Advanced Manufacturing & Engineering
☑Equipment Power: Equipped with world-class Gleason milling and grinding machines to ensure superior hardware-level accuracy.
Comparison of Common Materials
Category | International | China | Corresponding Application Scenarios |
Low Carbon Alloy Steel | SCM415 (SCr420H) | 20CrMnTi, 40Cr | Low-torque gears, low-speed heavy-duty gears |
Medium Carbon Alloy Steel | SCM440 (SCr440H) | 42CrMo, 45CrMo | High-load gears, automotive gearboxes |
High Carbon Steel / Quality Carbon Steel | S45C, S50C | No. 45 Steel, No. 50 Steel | Medium-low speed gears, general mechanical transmission |
Structural Steel | SS400 | Q235 | Low strength, non-critical structural components |
Engineering Plastics | MC Nylon, POM | MC Nylon, POM | Low speed, low load, high noise-reduction requirements |
Core Expertise & Customized Solutions
What to Do If Gear Noise Is Excessive?
Analysis of the Causes of Early Pitting Corrosion
